RXN305D Linear Single Output DC Programmable Power Supply 0~30V 0~5A

Linear Adjustable DC Power Supply RXN-305D

RXN Series Linear DC Adjustable Power Supply is equipment with high stability, high reliability, low noise, its output voltage or current can be continuously adjusted, and its constant voltage and current can auto-conversion. This low-cost and universal power supply can be used in many different areas, from test of R&D equipment to test of production lines.

Features:

• Single-channel output 0-30V/0-5A
• Internal radiator and electronic temperature control cooling fan (fan work temp. exceed 50 C)
• A Digital or pointer meter shows the voltage and current values
• Voltage/current adjust knob with rough and meticulous adjustable potentiometers can outputs constantly with high resolution
• A power supply of universal type with simplified function and highly cost-effective
• Current limiting protection and users can set the current limiting protection point arbitrarily
• Opposite polarity protection
• Plastic panel of the equipment is modern & simple.

Specification:

• Input voltage : 220V AC ±10% 50Hz
• Voltage output : 0 - 30V
• Current output : 0 - 5A
• Operating temperature : -10C - 40C
• Constant voltage state :
  • Voltage stability : ≤0.01% + 2mV
  • Load stability : ≤0.01% + 2mV
  • Resume time: ≤100us
  • Ripple noise: ≤1mVRMS (RMS)
  • Temperture coefficient : ≤200PPM/C
• Constant current state :
  • Current stability : ≤0.1% + 3mV
  • Load stability : ≤0.2% + 3mV
  • Ripple noise: ≤2mA RMS
  • Voltage display accuracy: Three-digit LED : ±1% ~ 3% ±1 unit
• Weight: 4.6kg
• Dimensions mm : 275×126×155

Package includes:

• RXN305D Main unit
• Power Cord (220 Vac)
• User Manual
