KXN3010D Switching Single Output DC Programmable Power Supply 0~30V 0~10A

https://www.ram-e-shop.com/web/image/product.template/8769/image_1920?unique=87720b8

DC Adjustable Switching Mode Power Supply

5,500.00 EGP 5500.0 EGP 5,500.00 EGP

5,500.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: PS.KXN3010D

Main Functions:

  • Current preset, current-limiting protection.
  • Automatic switching of constant voltage/constant current.
  • Three-digit display of voltage and current, with display accuracy 0.1V 0.01A
  • Low noise: Temperature-controlled fan is adopted, and it starts automatically to dissipate heat when internal temperature is greater than 50℃.

Electrical Specifications:

  • Model: KXN-3010D
  • Input voltage: AC 220V±10% 50Hz
  • Temperature: Working temperature: -10℃~40℃ Relative humidity<80%
  • Output voltage: 0-30Vdc
  • Output current: 0-10Adc
  • Voltage-stabilized state: Voltage stabilization degree ≤0.2%+2mV , Load stability ≤0.2%+2mV
  • Ripple noise: ≤0.3%Vp-p (Peak to peak)
  • Steady-flow state: Current stabilization degree ≤0.1%+3mA , Load stability ≤0.2%+3mA
  • Display accuracy: 3-digit LED digital display of voltage/current ±1% ±1 character
  • Display resolution: Voltage 0.1V Current 0.1A/0.01A
  • Boundary dimension: 275 (depth) * 126 (width) * 155 (height) mm
  • Weight:  2.14Kg

Package includes:

  • KXN3010D Main unit
  • Power Cord (220 Vac)
  • User Manual

Download

User Manual
