Micro Switch With Wheel - MS3


Limit Switch With Roller Wheel - Size 28.0 x 15.5 x 9.5 mm

13.00 EGP 13.0 EGP 13.00 EGP

13.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days

Internal Reference: MS.3.WHEEL

KW(JW) series microswitch is suitable for use in each kind of control circuit with a rated voltage less than 250V and rated current less than 20A (DC and AC effective value) for controlling elements, it is the sense switch with certain movement strength through the certain traveling to cause the electronic contact speed.

  • The dimensions of this limit switch is 28.0 x 15.5 x 9.5 mm.
  • Arm length 28mm

Voltage & Current Ratings:

  • AC 125 ~ 250V - 16A
  • DC 250V - 0.30A
  • DC 125V - 0.60A
