AD-55A Dual Output Power Supply (UPS / Charger Type)
General
- Series: AD-55 Dual Output Series
- Dimensions: 159 × 98 × 38 mm
- Warranty: 3 Years
- Certifications: CE, RoHS
-
Standards Compliance:
EN55022:2010 + AC:2011, EN61000-3-2, EN61000-4-2/3/4/5/6/8/11, EN60950-1
Features
- AC input power source suitable for worldwide use
- Protections: Short Circuit, Overload, Over Voltage, Over Temperature
- Built-in EMI filter with low ripple
- 100% full load burn-in test
- Conforms to CE / RoHS / ISO9001 safety standards
Output Specifications
Output Channels: 2 (CH1 + CH2 Charger Output)
| Parameter | CH1 | Charger Output |
|---|---|---|
| DC Voltage | 13.8V | 13.4V |
| Voltage Tolerance | ±2% | ±5% |
| Rated Current | 3.5A | 0.2A |
| Current Range | 0.2 ~ 3.5A | 0 ~ 0.2A |
| Rated Power | 55W (Total) | |
| Ripple & Noise | 80mVp-p | 100mVp-p |
| DC Voltage Adjustment Range | ±10% | ±10% |
Input Specifications
- AC Voltage Range: 85 ~ 264VAC / 120 ~ 370VDC
- AC Current: 0.8A
- Efficiency (Typ.): 75%
- Inrush Current: Cold start 36A
Protection
- Leakage Current: < 1.5mA @ 240VAC
-
Overload Protection:
115% ~ 135% of rated output power, overload protection with automatic recovery
Environmental
-
Working Temperature & Humidity:
−10°C ~ +60°C, 20% ~ 90% RH (non-condensing) -
Storage Temperature & Humidity:
−20°C ~ +85°C, 20% ~ 90% RH
