Smun® Industrial Power Supply SMPS EDR-Series
Description:
The EDR is a DIN rail-mounted switch-mode power supply, specifically designed for industrial applications and characterized by its efficiency, reliability, compactness, and ease of installation. Below is a detailed overview of this product:
Power & Output Voltage:
The EDR offers a rated output power of 75W/120W/150W and provides a single DC output voltage option of either 12V, 24V, or 48V, catering to various device power requirements.
Current Capacity:
Corresponding to the different output voltages, the maximum output currents are different.This ensures a steady and ample supply of DC power to connected loads.
DIN Rail Mounting:
Designed for DIN rail mounting, compliant with TS-35/7.5 or TS-35/15 standard rails, the power supply can be easily secured onto standard electrical cabinets or control boxes' DIN rails, facilitating quick, neat wiring and maintenance.
High Efficiency:
As a switch-mode power supply, the EDR typically boasts a high conversion efficiency (usually above85%), contributing to reduced energy consumption and thermal losses during operation.
Compact Size:
The product is designed with an extremely slim profile, especially with a thickness of just 32mm, making it space-saving and ideal for use in space-constrained industrial equipment or control enclosures.
Industrial Standards Compliance:
Conforms to stringent industrial-grade standards and certifications, such as CCC and CE, ensuring robust performance and safety even in harsh environmental conditions.
Features:
- Universal AC Input/Full Range
- Protections:Short circuit/Overload/Over voltage/Over temperature
- Cooling by free air convection
- Built-in EMI filter with minimal bellows
- Power protection level:IP31
- 100% full load burn-in test
- Comply with EN55022:2010+AC:2010+AC:2011/EN61000-32-2 and EN61000-4-2,3,4,5,6,8,11/EN60950-1
