Proximity Laser Sensor and Transmitter Module - Measure Distance Module

https://www.ram-e-shop.com/web/image/product.template/7442/image_1920?unique=9b97f50

Distance Measuring & Detection Module

700.00 EGP 700.0 EGP 700.00 EGP 950.00 EGP

700.00 EGP 950.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: KIT.PROXIMITY.LASER

Laser Transmitter Non-modulator Module for Distance 0.8m - the LASER is most accurate and stable for range detection and better than IR which can be affected by sun and surrounding lights.

Overview

  • Features boost circuit
  • Signal output indicator

Specifications

  • Effective distance: 0.8m (typical) and 1.5m (maximum)
  • Power: 2.5V ~ 5.0V
  • Dimension: 47.7mm * 17.9mm
  • Mounting hole size: 2.0mm

Applications

  • Obstacle detection
  • Pipeline counter
  • Smart robot
  • Obstacle-avoiding car

How to Use

  • In the case of working with an MCU:
    • VCC ↔ 2.5V ~ 5.0V
    • GND ↔ power supply ground
    • DOUT ↔ MCU.IO (digital output)
