Features
- Microcontroller: ESP-8266EX
- Operating Voltage: 3.3V Max (5V power from MicroUSB connector is internally converted to 3.3V)
- Digital I/O Pins: 11, all pins have interrupt/PWMI2C/one-wire support except D0
- Analog Input: 1 (3.2V max input)
- Connector: MicroUSB
- Clock Speed: 80MHz/160MHz
- Flash: 4M bytes
- Dimensions: 34mm x 25.5mm x 6.8mm
- Weight: Approx. 5g excluding connectors
- Compatible with Arduino
- Compatible with Nodemcu
- Compatible with MicroPython
