RAMPS 1.4 RepRap 3D Printer Arduino Mega2560 Shield (SKU#3D1000)

https://www.ram-e-shop.com/web/image/product.template/7264/image_1920?unique=9b97f50

225.00 EGP 225.0 EGP 225.00 EGP

225.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: KIT.3D.1000

The RAMPS 1.4 (RepRap Arduino Mega Shield) is an all-in-one design to fit the necessary components for a 3D printer into one plug-in shield for an Arduino MEGA. The plug-in shield design includes plug-in stepper drivers and extruder control electronics sockets for easy service, part replacement, upgradeability, and expansion.

Additionally, many Arduino expansion boards can be added to the system as long as the main RAMPS board is kept at the top of the stack. Ramps boards are the heart of most DIY 3D printers on the market and a nice clean compact way to integrate all the systems into a compact enclosure mountable format.

Features

  • Expandable to control other accessories.
  • 3 Mosfets for heater/fan outputs and 3 thermistor circuits.
  • Fused at 5A for additional safety and component protection.
  • Heated bed control with an additional 11A fuse.
  • Fits 5 stepper driver boards (A4988, DRV8825, .....).
  • Driver boards are on pin header sockets so they can be replaced easily or removed for use in future designs.
  • I2C and SPI pins are left available for future expansion.
  • All the Mosfets are hooked into PWM pins for versatility.
  • Servo-style connectors are used to connect to the end stops, motors, and LEDs. These connectors are rated for 3A, very compact, and globally available.
  • SD Card add-on available.
  • LEDs indicate when the heater outputs on.
  • Option to connect 2 motors to Z.
